PowerEdge XR11 Edge Server Supports up to 4 x 2.5″ SATA / SAS / NVMe drives

Dell PowerEdge XR11 Server – Specifications

Chassis & Form Factor

• Rugged 1U rack server (designed for edge & harsh environments)

• Rear Port Access configuration

• Supports up to 4 x 2.5″ SATA / SAS / NVMe drives

• Non-Air Filtered (NAF) chassis

• Brand or filtered bezel options available

Processor

• Intel® Xeon® Gold 5315Y

  • 8 Cores / 16 Threads

  • Base Frequency: 3.2 GHz

  • Turbo Boost enabled

  • Cache: 12 MB

  • TDP: 140W

  • Memory Support: DDR4-2933

(Supports Intel Xeon Gold & Silver scalable processors)

Memory

• 16GB DDR4 RDIMM (3200 MT/s) – Installed

• Dual Rank memory

• Performance-optimized memory configuration

• Supports RDIMM and LRDIMM

• Expandable for higher capacities

Storage

• 480GB 2.5″ SATA SSD (Read-Intensive)

• Hot-plug drive support

• Embedded SATA (No RAID configured)

• Supports NVMe, SATA, and SAS storage options

RAID & Controllers

• Embedded SATA controller

• No hardware RAID controller installed

• Software RAID supported (optional)

• BOSS (Boot Optimized Storage) optional

Networking

• Onboard Broadcom 57504 Quad-Port 25GbE SFP28

• Supports additional PCIe network adapters:

  • 1GbE, 10GbE, 25GbE options

  • Intel, Broadcom, NVIDIA/Mellanox supported

PCIe Expansion

• Rear Port Access PCIe Riser

• Slots:

  • 1 × PCIe x8

  • 2 × PCIe x16

• Supports GPUs, NICs, and accelerators

GPU & Acceleration Support

• Optional NVIDIA GPUs supported, including:

  • NVIDIA L4

  • NVIDIA Ampere A2

• Passive, low-profile and full-height options

Power Supply

• Single 800W Hot-Plug Power Supply

• Supports redundant PSU configurations

• AC power input supported (100–240V)

Security

• TPM 2.0 optional

• Secure boot support

• System secured component verification option

Management

• iDRAC9 Express

• Remote server management & monitoring

• UEFI BIOS with GPT partition support

• Performance BIOS profile enabled

Operating System

• No Operating System installed

• Compatible with:

  • Windows Server

  • Red Hat Enterprise Linux

  • SUSE Linux Enterprise

  • Ubuntu Server

  • VMware environments

Use Cases

• Edge computing

• Industrial & rugged deployments

• Telecommunications

• IoT infrastructure

• AI inference & acceleration at the edge
